DY-8 Desktop Ribbon Coder
Data sheet of date coding machine:
Applications:
It is applicable to printing notes like production date, lot number, price and weight on any soft packaging material such as PT, PE, KT, OPP, aluminum foil, paper bags, label, leather and so on.
Features:
1. Especially suitable for application in the field of food and medicine. It adopts thermal printing ribbon which can avoid oil contamination and keep the surrounding clean.
2. Adopts hot printing ribbons to print clear, easy drying, no-tacky and indelible characters.
3. Characterized by ingenious structure, compact size and convenient installation.
Technology Data:
|
Model |
DY-8 |
|
Driver |
Motor |
|
Voltage |
220V/50Hz |
|
Power |
40W |
|
Print Speed |
20-120 Times/min |
|
Font Size |
2mm*4mm*15mm (can be customized) |
|
Printing Ribbon Width |
Max. 30mm |
|
Printing Area |
One line 4*30mm |
|
Two lines 8*30mm |
|
|
Three lines 12*30mm |
|
|
Consumable |
Ribbon |
|
Weight |
3.8kg |
|
Dimension (L*W*H) |
250mm*150mm*240mm |
|
Package Size (L*W*H) |
290mm*195mm*270mm |
|
Remarks: Other specification can be customized. |
|
