NY-801B Manual Desktop Ink Roll Coder
NY-801B Desktop Ink Roll Coder
Ⅰ. Applications:
NY-801B is a desktop semi-automatic hot ink roll coder which not only can do automatic continuous printing but also can be controlled by foot switch to print date code, lot number and weight on paper boxes, labels and other various trademark labels.
Ⅱ. Features:
1. Made by high quality anodized aluminum and stainless-steel.
2. Adopts high quality solid ink roll, legible printing with lower print costs.
3. Can print 1-3 lines, adjustable print height, much wider printing areas.
Ⅲ. Technology Data:
Model |
NY-801B |
Driver |
Motor |
Voltage |
220V/50Hz |
Power |
150W |
Print speed |
0-150 Times/min |
Font size |
2mm*3.4mm*7.2mm |
Consumable |
Ink Roll |
Weight |
10kg |
Dimension (L*W*H) |
400mm*260mm*350mm |
Remarks: Other specification can be customized. |
